Compact Structure SFP Socket / Cage Connector Single Port With Heat Sink

Copper Alloy SFP Cage Connector Single Port With Heat Sink Press Fit Mount Type

develop and produce SFP cages to be fully compliant with the Multi-Source Agreement (MSA) specification. Used in either copper or optical applications, the cage construction is a one-piece, stamped and formed metal to offer the best performance for EMI shielding. Our single-port cage is designed with various pin and plating options to address press-fit and solder applications.

3) Heat Dissipation

Our thermally enhanced solutions offer better front-to-back and back-to-front airflow through the cages, providing better heat dissipation for industry leading thermal performance.

4) Signal Quality

To enhance signal quality, the SFP portfolio focuses on the latch-plate area to reduce EMI and avoid degradation of circuit performance and ensure compliance to standards. Products are offered in both an EMI spring and EMI elastomeric gasket versions to meet customer system requirements.

5) Key Features and Benefits, Performance and Flexibility

• Offers cages in single-port, ganged (1xN) and stacked (2xN) configurations; belly-to-belly mounting cages also offered
• Features elastomeric gaskets or springs for EMI containment
• Offers heat sink and light pipe options
• Stacked cages include an integrated high-speed connector
• Complementary to the SFP portfolio of direct-attach copper cable assemblies and LC optical connectors and cable assemblies
• Cages are available for PCI card applications ( one-degree mounting angle )

6) Applications

by Product

• Enterprise Storage: Server
• Networking: Router, Optical Transport Switch
• Telecommunications: Remote Radio Head, Base Station Switch

by Protocol

• SONET
• Gigabit Ethernet
• Fiber Channel
• Serial data transmission

Product Structure:

• 1 x 1 Single Port;
• Stampled and Formed Metal Cage;
• With Heat Sink For Heat dissipation;
• Without Light Pipes, Can be customized as required;
• Press Fit Mount Type, Can be customized as required;
• Cage Material : Copper Alloy
• Heat Sink Material : Aluminum
• CLIP : Stailness Steel
• With or Without Elastomeric gasket
• Cage Length : 48.7 mm
• Cage Width : 14.7 mm
• Cage Height : 9.55 mm

Customization Services

• 1 x n or 2 x n Structures
• With or without Light pipes
• With oe without Heat Sink
• With or without Elastomeric or metal gasket
• Cage with or without Integarted Connector
• With or Without EMI Spring Finger
