Place of Origin:
Shenzhen China
Certification:
UL , CE , CQC , ROHS
Production Description
1. Powercon waterproof plug connectors usually apply in indoor / outdoor screen .
2. Plug and socket waterproof connector
3. Powercon male and female waterproof connector
4. Screw terminal waterproof connector
Feature / Advantage / Application
Datasheet / Parameter of Connector
| Name | 3Pin powercon plug connector | ||
| Number of contacts | 3 | ||
| Operating current/voltage | 20A 500V | ||
| Contact diameter X number | φ2.0 | ||
| Withstanding voltage | 2500V | ||
| Protection level | IP44/IP65 | ||
| Cable specification | 2.5mm2 | ||
| Diameter range | MAXφ12mm | ||
| Operating temperature | -25℃ - 80℃ | ||
| Connecting mode | Self- Lock | ||
| Shell , insulating parts | PA66 | ||
| Material of copper needles | Copper alloy | ||
| Flame - resistant rating | UL94-V0 | ||
| Color of connector | Yellow and black | ||
| Certification | UL , CQC , CE ,ROHS | ||
| Cable | Rubber / pvc / nylon | ||
| Length of cable | Per your requirement | ||
| Wiring | Screw terminal | ||
| Application | LED display / power | ||
| Connector | Plug and socket | ||
| Warranty | 5 years | ||
Product Show - Powercon Plug and Socket
